SW-MOTECH saddle bag Legend Gear LS1, 9,8 liters storage space

Product Description: SW-MOTECH Saddlebag Legend Gear LS

The SW-MOTECH Saddlebag Legend Gear LS is robust and elegant. It offers flexible storage space with a water-repellent inner coating. Perfect for your adventures.

• Durable Canvas Sailcloth: Made from durable canvas sailcloth, combined with Napalon synthetic leather for a stylish yet resilient look.
• Adjustable Roll Closure: The large main compartment can be flexibly adjusted to your loading requirements with the practical Velcro/roll closure.
• Includes Waterproof Inner Bag: For heavier rain, the inner bag made of 210D polyamide offers secure protection, thanks to double PU coating.
• Innovative Mounting System: Loop fastenings in combination with the SLS holder (Order No. 70250510000) allow flexible height adjustment and secure hold.
• Shape Retention Even When Unloaded: A stable bottom and back wall ensure that the bag retains its shape, even when not fully packed.
• Versatile Applications: The bag can be mounted on the right or left, individually or in pairs, for maximum flexibility.

Product Description in Detail:

Legend Gear Saddlebag LS1 and LS2

Saddlebag for the SLS universal seat belt in high-quality classic look.

Details:

• robust, elegant, and stylish
• large main compartment, adjustable with Velcro/roll closure
• made of durable canvas sailcloth with high-quality Napalon synthetic leather
• water-repellent PU inner coating
• includes waterproof inner bag for heavier rain (210D polyamide, double PU-coated)
• shape retention even when unloaded thanks to stable bottom and back wall
• the innovative loop fastening system allows, with the additionally required SLS holder, secure hold and positioning at different heights
• thanks to the metal hooks of the fastenings, removable from the motorcycle in seconds - the fastenings do not need to be reset after each stop
• 2 loop straps, which are hooked in with metal hooks, provide stable lashing to the vehicle at the bottom
• 2 holders for rear attachment to the license plate screws provide additional attachment points for models where it otherwise becomes difficult
• includes protective film which protects the rear from coarse dirt or if the fastening straps run over sensitive parts
• numerous holding loops for individual attachment of optional Legend Gear accessory bags (see below)
• available in two heights for the preferred look or space conditions on the respective motorcycle

Dimensions (approx.):
LS1: 9.8 liters of storage space
LS1 Length x Width x Height outside: 31 x 14 x 26 cm
LS1 Length x Width x Height inside: 30 x 12 x 25 cm
LS2: 13.5 liters of storage space
LS2 Length x Width x Height outside: 31 x 14 x 35 cm
LS2 Length x Width x Height inside: 30 x 12 x 34 cm
NOTE: these are not static dimensions - the values can change due to loading and material flexibility!
Width of hook compression straps for lid: 3.8 cm
Width of hook compression straps on sides: 2.5 cm
Maximum length x width of loop straps: 75 x 2.5 cm
Weight LS1/LS2: 930/1110 g

Options:

• for attachment, the Legend Gear saddlebag holder SLS universal (Order No. 70250510000) is additionally required
• also available as a version for mounting on Legend Gear bag holders (Order No. 70250511000 and following)
• Legend Gear accessory bags for smartphone and/or other small items (Order No. 70230500020, 70230500030, 70230500040) can be securely fastened to the bag with the innovative fastening system
• clickable shoulder strap for easier transport of the bag without a motorcycle (Order No. 70250513000)
• security lock for securing the bag to the motorcycle (Order No. 70250500000, 70250500001)
• to protect the natural fiber from weather influences, we recommend impregnating the canvas cotton textile surface of the product at regular intervals or after intensive cleaning with a commercially available wax impregnation (Order No. 33012100004)

Price per piece

Universal Attachment Saddlebags (suitable for almost all motorcycles):

• the additionally required SLS seat belt is placed around the passenger seat (please do not pinch or hinder any components with the thin straps under the seat)
• the LS bag is then hung at the desired height on the cross connection using the supplied metal hooks
• the bag can be used on the right or left - alone on one side or on both sides
• after positioning the bag as desired, secure it at the bottom
• the supplied hook loop straps can be hooked into various loops to match the attachment point
• first lay the front loop strap (to frame tubes, footrest holder, etc.) so that neither your freedom of movement is restricted nor any non-load-bearing parts (e.g., rear fairing) are subjected to excessive stress
• then pull them just tight enough that the bag holds the position and cannot slide back significantly
• now individually find a load-bearing attachment point for the rear loop strap on each motorcycle
• this is usually the license plate holder, grab handle, frame tube, indicator mount (if stable enough), etc.
• the loop straps can be attached independently on the right and left - if this is not possible, they can also be connected to create a continuous strap from right to left when using two bags - usually laid between the license plate and its holder or splash guard
• the supplied holders can also be screwed to the license plate attachment towards the rear wheel (please do not place on the visible side of the license plate as it would otherwise be covered) - this provides two excellent lashing points
• please ensure that nothing is pinched or put under too much tension
• then pull the two loop straps just tight enough so that the bags are not yet completely tight
• check the desired position of the bags again and correct if necessary
• only then pull both loop straps evenly tight so that the bag sits stably and cannot slip even when loaded
• due to the achieved stability, no additional saddlebag holder is necessary for almost all models - but these can provide even more stability
• please secure the strap ends against fluttering - a rubber ring is included with the loop strap
• please always cautiously increase speed on the first rides or with new loading
